qml qml @mike_qml

4 years ago

Tekla Tool dropbox.com/sh/zx0pzdudmwf… #Tekla #SteelDetailing

0 0 0 0 0

Download Image

qml qml @mike_qml

4 years ago

Tekla Tool by myself, it's free now. dropbox.com/sh/zx0pzdudmwf…

0 0 0 0 0

Download Image

qml qml @mike_qml

4 years ago

Project Status Show #Tekla #SteelDetailing

0 0 0 0 0

Download Image

qml qml @mike_qml

4 years ago

dropbox.com/sh/zx0pzdudmwf… You can download my TeklaTools for trial

0 0 0 0 0

qml qml @mike_qml

4 years ago

Select special parts by below options from selected parts. #Tekla #SteelDetailing #TeklaOpenAPI

0 0 0 0 0

Download Image

2P Cloud: pick two points to create cloud. Delete All: delete all clouds in this drawing. Cloud Color: set color of cloud. Bulge: set bulge of cloud. Delete Component: delete components which connect to selected part. #Tekla #SteelDetailing

0 0 0 0 0

Download Image

qml qml @mike_qml

4 years ago

Trim Part: select a part, and a plane. Trim part by this plane. Align Beams Elev.: pick a beam as reference, then pick beams which elevation will be revised to align with reference. The aligned elevation was the top elevation of reference beam. #Tekla #SteelDetailing

0 0 0 0 0

Download Image

qml qml @mike_qml

4 years ago

Point Coordinate: pick a point, show its coordinate by using a leader line. Ref. Point: you can input point X, Y, Z value by hand, or use pick button to pick it in model. #Tekla #SteelDetailing #TeklaOpenAPI

0 0 0 0 0

Download Image

qml qml @mike_qml

4 years ago

Intersect Beam: pick two beams, let them intersect at one point if possible. BeamPlate To ContourPlate: update beam plate (plate with beam property) to contour plate. Divide Beam: divide beam into several parts. #Tekla #SteelDetailing

0 0 0 0 0

Download Image

qml qml @mike_qml

4 years ago

Secondary Dim: auto add all dimensions for secondary in the front view. Dim. Attribute: attribute file name of locating dimension for all secondary parts. Split Beam: split H shape over 3 plates. #Tekla #SteelDetailing

0 0 0 0 0

Download Image

qml qml @mike_qml

4 years ago

XY Dimension: pick two points, at last pick a point to place X & Y dimensions for the two points. Notch Dim: pick a part, auto add notch dimensions for it. Add Sections: auto add sections for all secondary parts, which was perpendicular to main part. #Tekla #SteelDetailing

0 0 0 0 0

Download Image

qml qml @mike_qml

4 years ago

Add Bolt Dimension: auto add all bolt dimensions in the front view. merge dist.: combine 2 bolt group into 1 bolt group in this distance. Reverse Bolt: reverse bolts in model #Tekla #SteelDetailing #TeklaOpenAPI

0 0 0 0 0

Download Image

qml qml @mike_qml

4 years ago

Bolts Triangle: pick a bolt group, auto add angle dimension by Triangle type. Bolts X & Y: pick a bolt group, auto add parallel dimensions for two directions. #Tekla #SteelDetailing #TeklaOpenAPI
