CircuitLab @CircuitLab

3 years ago

Beautiful!

CircuitLab Profile Picture

CircuitLab @CircuitLab

4 years ago

CircuitLab's academic sales office will be closed on Monday, May 31 in observance of Memorial Day. If you need assistance with your institution's site license purchase, we'll be back on Tuesday. Self-service site license purchase via credit card remains open 24/7.

CircuitLab Profile Picture

CircuitLab @CircuitLab

4 years ago

Thanks @AlvindeDiaspar! Glad to hear it!

CircuitLab Profile Picture

CircuitLab @CircuitLab

4 years ago

Last week we pushed 0 commits to @CircuitLab. We're busy supporting university customers through the spring semester. Does your university need free CircuitLab access for all students and faculty? Contact us about educational site licenses.

CircuitLab Profile Picture

CircuitLab @CircuitLab

4 years ago

Last week we pushed 1 commit to @CircuitLab, fixing a UI edge case where current and voltage tooltips were not always showing up properly in Live DC simulation.

CircuitLab Profile Picture

CircuitLab @CircuitLab

4 years ago

Last week we pushed 13 commits to @CircuitLab, including a new "Simulation Troubleshooting" documentation page to help new users get their circuits working faster by avoiding the most common types of simulation errors. circuitlab.com/docs/simulatio…

CircuitLab Profile Picture

CircuitLab @CircuitLab

4 years ago

Last week we pushed 22 commits to @CircuitLab: improving error message readability when a circuit is invalid; allowing a lenient leading "+" within numeric UI input fields and behavioral source expressions; fixing an internal state management issue with "Save As"; and more!

CircuitLab Profile Picture

CircuitLab @CircuitLab

4 years ago

Last week we pushed 1 commit to @CircuitLab, resolving a frontend exception for people using some browser extensions.

CircuitLab Profile Picture

CircuitLab @CircuitLab

4 years ago

Last week we pushed 19 commits to @CircuitLab, mostly fixing exceptions on a front-end bug hunt.

CircuitLab Profile Picture

CircuitLab @CircuitLab

4 years ago

Last week, we pushed 22 commits to @CircuitLab. Highlights: - convergence fixes in the simulator, especially around the Ideal Diode component - fix edge case in DC Sweep simulation - improved purchasing flow for our university site license customers

CircuitLab Profile Picture

CircuitLab @CircuitLab

5 years ago

Last week we pushed 33 commits to @CircuitLab. Highlights: - fixed a backend race condition that sometimes prevented saved circuits from rendering - high-resolution timestamps in simulator internals - dark mode on ultimateelectronicsbook.com

CircuitLab Profile Picture

CircuitLab @CircuitLab

5 years ago

We've been back up and stable for 2+ hours after networking issues at our hosting provider were fixed. Last week we pushed 13 commits to @CircuitLab. Highlight: better documentation on circuitlab.com/docs/ covering advanced topics like inductor coupling coefficients.

CircuitLab Profile Picture

CircuitLab @CircuitLab

5 years ago

Hacker News is down. So is CircuitLab. Same datacenter. Monitor the incident here: status.m5hosting.com/pages/incident…

CircuitLab Profile Picture

CircuitLab @CircuitLab

5 years ago

CircuitLab is temporarily unavailable as our hosting provider is experiencing network issues. We're monitoring the situation and should be back soon.

CircuitLab Profile Picture

CircuitLab @CircuitLab

5 years ago

Last week we pushed 2 commits to @CircuitLab. This includes a fix for users signing up with some unusual top-level domains in their email address. (If you're still having problems creating an account, let us know.)

CircuitLab Profile Picture

CircuitLab @CircuitLab

5 years ago

Last week we pushed 21 commits to @CircuitLab, focusing on adding 13 CircuitLab Academy onboarding lessons to help new users get started drawing & simulating circuits productively: circuitlab.com/docs/#academy

CircuitLab Profile Picture

CircuitLab @CircuitLab

5 years ago

Last week we pushed 40 commits to @CircuitLab, including a new Digital Probe element which updates to show live DC values as you change your schematic. This is available alongside the Voltmeter and Ammeter in the "Probes / Meters" of the CircuitLab toolbox.

CircuitLab Profile Picture

CircuitLab @CircuitLab

5 years ago

Last week we pushed 12 commits to @CircuitLab. Highlight: improvements to the Toolbox Search so you can draw your circuit even faster. (Shortcut: press / [forward slash] to begin a search!)

CircuitLab Profile Picture

CircuitLab @CircuitLab

5 years ago

Last week we pushed 41 commits to @CircuitLab, improving tooltips on digital gates (mouse over and see!) and adding a digital query mode to the simulation engine, i.e. D(Q[3:0]). For example try circuitlab.com/editor/z7wv8vt… -- just click "Run Time-Domain Simulation."

CircuitLab Profile Picture

CircuitLab @CircuitLab

5 years ago

Last week we pushed 20 commits to @CircuitLab, including simulator bugfixes on the backend, and launching Live DC simulation mode on the frontend. (Have you tried drawing a circuit and hovering over wires and elements yet?)
